DB Drive G7 150.4 : 4-Channel Class D Amplifier
Regular price
$499.98
Unit price
DB Drive G7 150.4 : 4-Channel Class D Amplifier is backordered and will ship as soon as it is back in stock.
Pickup available at Audio Hoggz
Usually ready in 24 hours
Delivery and Shipping
Delivery and Shipping
Please allow 2-3 business days for shipments to process.
DB Drive G7 150.4 : 4-Channel Class D Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Features
- ATC – Audiophile Grade Tiffany RCA Connectors
- ACT – Adaptive Crossover Technology
- High efficiency Class D Technology
- Direct Connect Speaker Terminals
- 4 Gauge Power Wire Inputs
- APC – Audio Protection Circuit
- SESI – Signal Evaluation Status Indicator
- CHM – Collective Heat Management
Specifications
| Rated Power @14.4 Volts | |
|---|---|
| 4 x 125 Watts @ 4Ω | |
| 4 x 250 Watts @ 2Ω | |
| 2 x 500 Watts @ 4Ω Bridged | |
| SPECIFICATIONS | |
| Working Voltage | 10 - 16 Volts |
| Frequency Response | 20Hz - 30KHz |
| Signal to Noise Ratio | <85dB |
| Damping Factor | 100dB< |
| Low Level Input | 6V - 0.2V |
| ACT - Variable Crossover | HP/BP/LP |
| Ch 1/2 High Pass Filter Variable | 20Hz - 8KHz |
| Ch 1/2 Low Pass Filter Variable | 50Hz - 8KHZ |
| Ch 3/4 High Pass Filter Variable | 20Hz - 8Khz |
| Ch 3/4 Low Pass Filter Variable | 50Hz - 8KHz |
| Minimum Working Impedance | 2 Ohms |
Dimensions
L = 7.87"/ 200 mm
W = 9.13"/ 232 mm
H =2.53"/ 64.5 mm
Description
Discover the future of sound with the G7 150.4 Class AB 4 Channel Amplifier! This powerhouse of audio innovation transforms your listening experience with cutting-edge features like ATC – Audiophile Grade Tiffany RCA Connectors and ACT – Adaptive Crossover Technology. Feel the pulse with high-efficiency Class D Technology and enjoy seamless integration with Direct Connect Speaker Terminals. With 4 Gauge Power Wire Inputs and APC – Audio Protection Circuit, your audio is not only powerful but protected. The SESI – Signal Evaluation Status Indicator and CHM – Collective Heat Management ensure optimal performance, while the Variable 12dB 3-Way Active Crossover offers unparalleled sound customization. With a frequency response of 20Hz to 30KHz and an impressive signal-to-noise ratio of <85dB, every note is crystal clear. Offering a rated power of 4 x 250 Watts at 2Ω and bridgeable to 2 x 500 Watts at 4Ω, the G7 150.4 is ready to redefine your audio landscape. Upgrade to the G7 AMPLIFIERS series and experience sound like never before – pure, powerful, and precise!
Product Manual
Product Manual PDF
